Setting Up an ATM Configuration
This section lists the steps required to set up the ATM configuration example
shown in
Figure 1-14 on page 1-36.
For ATM terminology, as well as concepts and examples of how the BayStack
450-2M3/2S3 MDAs operate within an ATM environment, see
Appendix D,
“ATM Overview.”
To set up the ATM configuration:
1. Create VLAN 1, including S1 (PC 1) and S2 (PC 1) as VLAN members,
and also set the appropriate PVIDs for the respective PC ports.
See “VLAN Configuration Menu” on page 3-44 for help in creating VLANs.
2. Create an ELAN (ELAN 1) on the Centillion 100 switch.
Refer to the Centillion 100 switch documentation.
3. Configure a virtual port (VPort LEC 1) on S1 that corresponds to
VLAN 1 and ELAN 1.
Refer to “ATM Configuration Menu” on page 3-89.
4. Configure a virtual port (VPort LEC 1) on S2 that corresponds to
VLAN 1 and ELAN 1.
5. Repeat steps 1 to 4 for each of the three remaining LECs within the
BayStack 450-2M3/2S3 MDAs.
For details about creating VLANs, see “VLAN Configuration Menu” on
page 3-44.
For details about configuring the BayStack 450-2M3/2S3 MDA using the CI
menus and screens, refer to
“ATM Configuration Menu” on page 3-89.
Appendix E, “Quick Steps to Features,” provides flowcharts that you can use as
quick configuration guides for the BayStack 450 switch features.
See the Nortel Networks library Web page: www25.nortelnetworks.com/library/
for online documentation about the Nortel Networks Centillion 100 switch.
Note: Certain spanning tree considerations apply when configuring VPorts
(see
“Spanning Tree on LEC VPorts” on page D-11).
