Using the BayStack 450 10/100/1000 Series Switch
3-100 309978-D Rev 01
Console/Comm Port Configuration
The Console/Comm Port Configuration screen (Figure 3-40) allows you to
configure and modify the console/comm port parameters and security features of a
standalone switch or any participating switch in a stack configuration.
Choose Console/Comm Port Configuration (or press o) from the main menu to
open the Console/Comm Port Configuration screen.
Figure 3-40. Console/Comm Port Configuration Screen
Table 3-36 describes the Console/Comm Port Configuration screen fields.
Table 3-36. Console/Comm Port Configuration Screen Fields
Field Description
Comm Port Data Bits A read-only field that indicates the current console/comm port data bit setting.
Comm Port Parity A read-only field that indicates the current console/comm port parity setting.
(continued)
Console/Comm Port Configuration
Comm Port Data Bits: 8 Data Bits
Comm Port Parity: No Parity
Comm Port Stop Bits: 1 Stop Bit
Console Port Speed: [ 9600 Baud ]
Console Switch Password Type: [ None ]
Console Stack Password Type: [ None ]
TELNET Switch Password Type: [ None ]
TELNET Stack Password Type: [ None ]
Console Read-Only Switch Password: [ user ]
Console Read-Write Switch Password: [ secure ]
Console Read-Only Stack Password: [ user ]
Console Read-Write Stack Password: [ secure ]
Primary RADIUS Server: [ 0.0.0.0 ]
Secondary RADIUS Server: [ 0.0.0.0 ]
RADIUS UDP Port: [ 1645 ]
RADIUS Shared Secret: [ ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
