Using the BayStack 450 10/100/1000 Series Switch
3-86 309978-D Rev 01
Table 3-31 describes the Port Statistics screen fields.
Note: In a stacked configuration, the Port Statistics screen appears in a slightly
different format when the port selected in the Unit/Port field is configured with
a gigabit MDA.
Table 3-31. Port Statistics Screen Fields
Field Description
Unit Appears only if the switch is participating in a stack configuration. The field allows
you to select the number of the unit you want to view or configure. To view or
configure another unit, type its unit number and press [Enter], or press the
spacebar on your keyboard to toggle the unit numbers.
Port Allows you to select the number of the port you want to view or reset to zero.
To view another port, type its port number and press [Enter], or press the spacebar
on your keyboard to toggle the port numbers.
Packets Received column: Indicates the total number of packets received on this port,
including bad packets, broadcast packets, and IP multicast packets.
Transmitted column: Indicates the total number of packets transmitted successfully
on this port, including broadcast packets and IP multicast packets.
Multicasts Received column: Indicates the total number of good IP multicast packets received
on this port, excluding broadcast packets.
Transmitted column: Indicates the total number of IP multicast packets transmitted
successfully on this port, excluding broadcast packets.
Broadcasts Received column: Indicates the total number of good broadcast packets received
on this port.
Transmitted column: Indicates the total number of broadcast packets transmitted
successfully on this port.
Total Octets Received column: Indicates the total number of octets of data (including data in
bad packets) received on this port, excluding framing bits but including FCS octets.
Transmitted column: Indicates the total number of octets of data transmitted
successfully on this port, including FCS octets.
Lost Packets Received column: Indicates the total number of packets lost (discarded) when the
capacity of the port receive buffer was exceeded.
Transmitted column: Indicates the total number of packets lost (discarded) when
the capacity of the port transmit buffer was exceeded.
(continued)
