Using the BayStack 450 10/100/1000 Series Switch
A-2 309978-D Rev 01
Electrical
Physical Dimensions
Performance Specifications
Parameter Model 450-24T Model 450-12T/12F
Input Voltage 100 to 240 VAC @ 50 to 60 Hz 100 to 240 VAC @ 50 to 60 Hz
Input Power
Consumption
150 W maximum 120 W maximum
Input Volt Amperes
Rating
200 VA maximum 150 VA maximum
Input Current 2.0 A @ 100 VAC 1.5 A @ 100 VAC
Maximum Thermal
Output
500 BTU/hr 400 BTU/hr
Parameter Specifications
Height 7.03 cm (2.77 in.)
Width 44.07 cm (17.55 in.)
Depth 38.1 cm (15.0 in.)
Weight 5.26 kg (11.60 lb)
Parameter Specifications
Frame Forward Rate
(64-byte packets)
Up to 3 million packets per second (pps) maximum, learned
unicast traffic
Port Forwarding/
Filtering Performance
(64-byte packets)
• For 10 Mb/s: 14,880 pps maximum
• For 100 Mb/s: 148,810 pps maximum
• For 1000 Mb/s: 1,488,100 pps maximum
• For ATM: 350,000 pps per port maximum (total
bidirectional)
Address Database Size 16,000 entries at line rate (32,000 entries without flooding)
Addressing 48-bit MAC address
Frame Length 64 to 1518 bytes (IEEE 802.1Q Untagged)
64 to 1522 bytes (IEEE 802.1Q Tagged)
