Using the Console Interface
309978-D Rev 01 3-49
User-Defined PID Allows you to create your own user-defined protocol-based VLAN where you specify
the Protocol Identifier (PID) for the VLAN. To set this field, the VLAN State field must
be set to Inactive (some restrictions apply, see
“User-Defined Protocol Identifier
(PID) Description” on page 3-51).
Default 0x0000
Range Any 4-bit hexadecimal value (for example, 0xABCD)
VLAN State Allows you to activate your newly created VLAN.
• The following associated field values: VLAN Type, Protocol Id (PID), and
User-Defined PID must be configured appropriately before this field can be set
to Active.
• After you set the VLAN State field value to Active, you cannot change the VLAN
Type, Protocol Id, or User-defined PID field values, unless you delete the VLAN.
• If you delete a VLAN, all configuration parameters that are associated with that
VLAN are deleted also.
Default Inactive (for all VLANs except VLAN 1)
Range Inactive, Active
Port Membership Allows you to assign VLAN port memberships to standalone or stacked unit ports.
The ports can be configured in one or more VLANs. To set this field, you must set
the VLAN State field value to Active.
Certain restrictions apply for gigabit ports and when using the BayStack 410-24T
switch ports as participants of protocol-based VLANs (see
“Gigabit Ports and
BayStack 410-24T Switch Ports Restriction” on page 3-52).
This field depends on the Tagging field value in the VLAN Port Configuration screen.
For example:
• When the Tagging field is set to Untagged Access, you can set the Port
Membership field as an untagged port member (U) or as a non-VLAN port
member (-).
• When the Tagging field is set to Ta g ge d Tr u n k , you can set the Port Membership
field as a tagged port member (T) or as a non-VLAN port member (-).
(see the Tagging field description in Table 3-17 on page 3-53).
The Port Membership fields are displayed in six-port groups (for example, 1-6, 7-12,
13-18). The number of ports displayed depends on the switch model or type of
optional MDA installed in the Uplink Module slot.
Default U (All ports are assigned as untagged members of VLAN 1.)
Range U, T, and -
Table 3-14. VLAN Configuration Screen Fields (continued)
Field Description
