Using the BayStack 450 10/100/1000 Series Switch
1-4 309978-D Rev 01
Comm Port
The Comm Port (also referred to as the Console/Comm Port) allows you to access
the console interface (CI) screens and customize your network using the supplied
menus and screens (see
Chapter 3, “Using the Console Interface”).
The Console/Comm Port is a DB-9, RS-232-D male serial port connector. You can
use this connector to connect a management station or console/terminal to the
switch by using a straight-through DB-9 to DB-9 standard serial port cable (see
“Console/Comm Port” on page 2-10).
The console port default settings are: 9600 baud with 8 data bits, 1 stop bit, and no
parity as the communications format, with Flow control set to Xon/Xoff.
Uplink/Expansion Module Slot
The Uplink/Expansion Module slot allows you to attach optional media dependent
adapters (MDAs) that support a range of media types (see
Appendix C, “Media
Dependent Adapters” for more information about MDA types available from
Nortel Networks).
10BASE-T/100BASE-TX Ports
Your BayStack 450-24T and BayStack 450-12T switches use
10BASE-T/100BASE-TX RJ-45 (8-pin modular) port connectors.
Note: The Console/Comm Port is configured as a data communications
equipment (DCE) connector. Ensure that your RS-232 cable pinouts are
configured for DCE connections (see “
DB-9 (RS-232-D) Console/Comm Port
Connector” on page F-5).
Note: The RJ-45 port connectors on BayStack 450 switches manufactured
prior to December 1998 are numbered 1 to 12 and 13 to 24, in succession from
left to right. Later units use port connectors that are configured with one or two
dual, six-port groups, numbered 1 to 12 and 13 to 24. The top rows are odd
numbered and the bottom rows are even numbered (see
Figure 1-2 on
page 1-3). Port-specific examples in this guide show the appropriate port
connections when required; other examples apply to both versions.
