Using the BayStack 450 10/100/1000 Series Switch

3-38 309978-D Rev 01

Figure 3-15. MAC Address Security Table Screen

Table 3-11 describes the MAC Address Security Configuration screen fields.

Note: The following screen shows an example of typical user input in

boldface type.

MAC Address Security Table

Find an Address: [ 00-00-00-00-00-00 ]

MAC Address Allowed Source MAC Address Allowed Source

----------- -------------- ----------- --------------

[ 44-33-22-44-55-44 ] [ S1 ] [ - - - - - ] [ ]

[ 22-44-33-55-66-55 ] [ S2 ] [ - - - - - ] [ ]

[ 22-55-33-44-33-22 ] [ S3 ] [ - - - - - ] [ ]

[ 44-22-33-55-44-22 ] [ S4 ] [ - - - - - ] [ ]

[ 22-33-44-55-33-44 ] [ S3 ] [ - - - - - ] [ ]

[ - - - - - ] [ ] [ - - - - - ] [ ]

Screen 1 More...

Press Ctrl-N to display next screen.

Enter MAC Address, xx-xx-xx-xx-xx-xx, press <Return> or <Enter> when complete.

Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
