Nortel BayStack 450-24T - Figure 3-27. Multilink Trunk Utilization Screen (1 of 2)

Using the Console Interface
309978-D Rev 01 3-69
Figure 3-27. MultiLink Trunk Utilization Screen (1 of 2)
MultiLink Trunk Utilization
Trunk Traffic Type Unit/Port Last 5 Minutes Last 30 Minutes Last Hour
----- ------------- --------- -------------- --------------- ---------
1 [ Rx and Tx ] 3/6 90.0% 70.0% 90.0%
3/7 20.0% 55.0% 80.0%
3/9 35.0% 45.0% 45.0%
3/17 85.0% 35.0% 20.0%
2 [ Rx and Tx ] 4/25 45.0% 45.0% 50.0%
4/26 25.0% 70.0% 35.0%
3 [ Rx and Tx ] 6/13 35.0% 35.0% 50.0%
6/14 30.0% 80.0% 70.0%
4 [ Rx and Tx ] 5/19 40.0% 35.0% 75.0%
5/20 25.0% 70.0% 85 0%
More...
Press Ctrl-N to display utilization for trunks 5-6.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
