Using the Console Interface
309978-D Rev 01 3-75
Rate Limiting Configuration
The Rate Limiting Configuration screen allows you to limit the forwarding rate of
broadcast and IP multicast packets.
Figures 3-30 and 3-31 show sample rate-limiting values for the two Rate Limiting
Configuration screens.
Choose Rate Limiting Configuration (or press l) from the Switch Configuration
Menu to open the Rate Limiting Configuration screen.
Figure 3-30. Rate Limiting Configuration Screen (1 of 2)
Note: If a port is configured for rate limiting, and it is a MultiLink trunk
member, all trunk member ports implement rate limiting. Also, if a trunk
member is implementing rate limiting and the port is disabled from rate
limiting, all trunk members are disabled from rate limiting.
Rate Limiting Configuration
Unit: [ 1 ]
Port Packet Type Limit Last 5 Minutes Last Hour Last 24 Hours
---- ------------- -------- -------------- --------- -------------
1 [ Both ] [ None ] 56.0% 22.0% 23.0%
2 [ Multicast ] [ 9% ] 30.0% 27.0% 55.0%
3 [ Both ] [ None ] 25.0% 24.0% 67.0%
4 [ Both ] [ 10% ] 72.0% 33.0% 55.0%
5 [ Broadcast ] [ 10% ] 35.0% 54.0% 78.0%
6 [ Multicast ] [ 10% ] 96.0% 45.0% 87.0%
7 [ Both ] [ 10% ] 86.0% 67.0% 60.0%
8 [ Both ] [ 5% ] 58.0% 44.0% 70.0%
9 [ Multicast ] [ None ] 11.0% 87.0% 65.0%
10 [ Both ] [ None ] 27.0% 89.0% 44.0%
11 [ Both ] [ None ] 15.0% 66.0% 66.0%
12 [ Both ] [ None ] 12.0% 98.0% 99.0%
13 [ Both ] [ None ] 44.0% 33.0% 89.0%
14 [ Both ] [ None ] 34.0% 45.0% 76.0%
More...
Press Ctrl-N to display choices for additional ports..
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
