Using the Console Interface
309978-D Rev 01 3-11
BootP Request Mode
The BootP Request Mode field in the IP Configuration screen allows you to
choose which method the switch uses to broadcast BootP requests:
• BootP Disabled
• BootP or Last Address
• BootP When Needed
•BootP Always
Default Gateway The IP address of the default gateway.
Default 0.0.0.0 (no IP address assigned)
Range Four-octet dotted-decimal notation, where each octet is represented
as a decimal value, separated by a decimal point
IP Address to
Ping
The IP address of the station you want to verify using the ping feature.
Default 0.0.0.0 (no IP address assigned)
Range Four-octet dotted-decimal notation, where each octet is represented
as a decimal value, separated by a decimal point
Start Ping Allows you to ping the target IP address entered in the IP Address to Ping field (above).
Default No
Range No, Yes
Note: Whenever the switch is broadcasting BootP requests, the BootP process
will time out if a reply is not received within (approximately) 7 minutes. When
the process times out, the BootP request mode automatically changes to BootP
Disabled mode. To restart the BootP process, change the BootP request mode
to any of the three following modes: BootP When Needed, BootP Always, or
BootP or Last Address.
Table 3-2. IP Configuration/Setup Screen Fields (continued)
Field Description
