Nortel BayStack 450-24T User Manual

Using the BayStack 450 10/100/1000 Series Switch
3-72 309978-D Rev 01
Figure 3-29. Port Mirroring Configuration Screen
Port Mirroring Configuration
Monitoring Mode: [ -> Port X or Port Y -> ]
Monitor Unit/Port: [ 3/12 ]
Unit/Port X: [ 4/5 ]
Unit/Port Y: [ 4/6 ]
Address A: [ 00-00-00-00-00-00 ]
Address B: [ 00-00-00-00-00-00 ]
Port mirroring configuration has taken effect.
Currently Active Port Mirroring Configuration
---------------------------------------------
Monitoring Mode: -> Port X or Port Y -> Monitor Unit: 3 Port: 12
Unit X: 4 Port X: 5 Unit Y: 4 Port Y: 6
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
