Using the Console Interface
309978-D Rev 01 3-9
IP Configuration/Setup
The IP Configuration/Setup screen (Figure 3-3) allows you to set or modify the
BayStack 450 switch IP configuration parameters and to verify a station’s IP
address using the ping feature. Data that you enter in the user-configurable fields
takes effect as soon as you press [Enter].
Choose IP Configuration/Setup (or press i) from the main menu to open the
IP Configuration/Setup screen.
Figure 3-3. IP Configuration/Setup Screen
Note: The read-only fields in this screen are updated based on the BootP mode
specified in the BootP Request Mode field. (See
“BootP Request Mode” on
page 3-11 for more information.)
IP Configuration/Setup
BootP Request Mode: [ BootP Disabled ]
Configurable In Use Last BootP
------------------- --------------- ---------------
In-Band Stack IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Switch IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Subnet Mask: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Default Gateway: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
IP Address to Ping: [ 0.0.0.0 ]
Start Ping: [ No ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
