Using the BayStack 450 10/100/1000 Series Switch
3-60 309978-D Rev 01
Figure 3-23. Port Configuration Screen (2 of 2)
Table 3-20 describes the Port Configuration screen fields.
Note: When a gigabit MDA is installed, only the Status field for that MDA
port is configurable. See
“High Speed Flow Control Configuration” on
page 3-62 to set the Autonegotiation field for the gigabit MDA port. Gigabit
MDAs only support 1000 Mb/s in full-duplex mode.
Port Configuration
Unit: [ 1 ]
Port Trunk Status Link LnkTrap Autonegotiation Speed Duplex
---- ----- ------------ ----- ------- --------------- -----------------
15 [ Enabled ] Down [ Off ] [ Disabled ] [ 10Mbs / Full ]
16 [ Enabled ] Down [ Off ] [ Disabled ] [ 100Mbs / Full ]
17 1 [ Enabled ] Up [ On ] [ Enabled ] [ 100Mbs / Full ]
18 [ Enabled ] Down [ On ] [ Disabled ] [ 100Mbs / Half ]
19 3 [ Enabled ] Up [ On ] [ Enabled ] [ 100Mbs / Full ]
20 3 [ Enabled ] Up [ On ] [ Enabled ] [ 100Mbs / Full ]
21 [ Enabled ] Down [ On ] [ Enabled ] [ 100Mbs / Full ]
22 4 [ Enabled ] Up [ On ] [ Enabled ] [ 100Mbs / Full ]
23 4 [ Enabled ] Up [ On ] [ Enabled ] [ 100Mbs / Full ]
24 [ Enabled ] Down [ On ] [ Disabled ] [ 100Mbs / Full ]
25 [ Enabled ] Down [ Off ] [ Disabled ] [ 100Mbs / Full ]
26 [ Enabled ] Down [ Off ] [ Disabled ] [ 100Mbs / Full ]
27 [ Enabled ] Down [ Off ] [ Disabled ] [ 100Mbs / Full ]
28 [ Enabled ] Down [ Off ] [ Disabled ] [ 100Mbs / Full ]
Switch [ Enable ] [ On ] [ Enable ] [ 100Mbs / Full ]
Stack [ Enable ] [ On ] [ Enable ] [ 100Mbs / Full ]
Press Ctrl-P to display choices for ports 1-14.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
To Next Page
