Using the BayStack 450 10/100/1000 Series Switch
3-74 309978-D Rev 01
Table 3-26 describes the various monitoring modes available from the Port
Mirroring Configuration screen.
Address B Indicates the MAC addresses that will be monitored by the designated port monitor
when one of the address-based monitoring modes is selected. This port will be
monitored according to the value of Address B in the selected Monitoring Mode field
(see
Tabl e 3-26). Users can enter the MAC address from this screen or from the MAC
Address Table screen. The entry is displayed and can be modified by either screen
(see “MAC Address Table” on page 3-22).
Default 00-00-00-00-00-00 (no MAC address assigned)
Range 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
Table 3-26. Monitoring Modes
Fields Description
Port-based:
Disabled Default value for this feature.
-> Port X Monitor all traffic Port X receives.
Port X -> Monitor all traffic Port X transmits.
<-> Port X Monitor all traffic Port X receives and transmits.
-> Port X or Port Y -> Monitor all traffic Port X receives or Port Y transmits.
-> Port X and Port Y -> Monitor all traffic Port X receives (destined to Port Y), and then Port Y
transmits.
<-> Port X and Port Y <-> Monitor all traffic Port X receives/transmits and Port Y
receives/transmits.
Address-based:
Disabled Default value for this feature.
Address A -> any Address Monitor all traffic Address A transmits to any address.
any Address -> Address A Monitor all traffic Address A receives from any address.
<-> Address A Monitor all traffic Address A receives or transmits.
Address A -> Address B Monitor all traffic Address A transmits to Address B.
Address A <-> Address B Monitor all traffic between Address A and Address B (conversation
between the two stations).
Table 3-25. Port Mirroring Configuration Screen Fields (continued)
Field Description
