Using the Console Interface
309978-D Rev 01 3-65
Choose MultiLink Trunk Configuration (or press t) from the Switch Configuration
Menu to open the MultiLink Trunk Configuration Menu.
Figure 3-25. MultiLink Trunk Configuration Menu
Table 3-22 describes the MultiLink Trunk Configuration Menu options.
Table 3-22. MultiLink Trunk Configuration Menu Options
Option Description
MultiLink Trunk
Configuration...
Displays the MultiLink Trunk Configuration screen (Figure 3-26). This screen
allows you to configure up to six MultiLink trunks within a standalone switch or
within a stack configuration. You can group up to four switch ports to form each
trunk.
MultiLink Trunk
Utilization...
Displays the MultiLink Trunk Utilization screen (Figure 3-27 and Figure 3-28).
This screen allows you to monitor the bandwidth utilization of the configured
trunks.
Return to Switch
Configuration Menu
Exits the MultiLink Trunk Configuration Menu and displays the Switch
Configuration Menu.
MultiLink Trunk Configuration Menu
MultiLink Trunk Configuration...
MultiLink Trunk Utilization...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
