BayStack 450 10/100/1000 Series Switches
309978-D Rev 01 1-51
The BayStack 450 switch allows you to assign ports to VLANs using the console,
TELNET, or any generic SNMP-based network management software. You can
assign different ports (and therefore the devices attached to these ports) to
different broadcast domains. This feature allows network flexibility because you
can reassign VLANs to accommodate network moves, additions, and changes,
eliminating the need to change physical cabling.
Figure 1-22. Port-Based VLAN Example
BayStack 450-24T
switch
VLAN 1 VLAN 2
BS45009A
