BayStack 450 10/100/1000 Series Switches
309978-D Rev 01 1-65
Figure 1-37. Default VLAN Port Configuration Screen Example
Figure 1-38 shows the VLAN Port Configuration screen after it is configured to
support the PVID assignment for port 8 (as shown in Figure 1-34). The Port Name
field is optional.
As shown in Figure 1-38, the PVID/VLAN association for VLAN 3
is now PVID = 3.
VLAN Port Configuration
Unit: [ 1 ]
Port: [ 1 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Unit 1, Port 1 ]
PVID: [ 1 ]
Port Priority: [ 0 ]
Tagging: [ Untagged Access ]
AutoPVID (all ports): [ Disabled ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
