Figure 1-38. VLAN Port Configuration Screen Example
The preceding example explains how to manually configure the PVID/VLAN
association to PVID 3. However, if you set the AutoPVID field value to Enabled
before creating the VLAN port memberships, the PVID/VLAN association is
automatically assigned a value that is associated with the VLAN number you
create.
See “VLAN Port Configuration” on page 3-52, for more information.
Note: You can also automatically assign a PVID/VLAN association for each
VLAN port membership you create.
VLAN Port Configuration
Unit: [ 1 ]
Port: [ 8 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Dan’s port ]
PVID: [ 3 ]
Port Priority: [ 0 ]
Tagging: [ Untagged Access ]
AutoPVID (all ports): [ Disabled ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
