Using the Console Interface
309978-D Rev 01 3-47
Figure 3-18. VLAN Configuration Screen
Table 3-14 describes the VLAN Configuration screen fields.
Table 3-14. VLAN Configuration Screen Fields
Field Description
Create VLAN Allows you to set up or view configured VLAN workgroups. Enter the number of the
new VLAN you want to create or view, and then press [Enter]. The Port Membership
fields indicate the corresponding VLAN workgroup configuration, if configured, or all
dashes (-), indicating no VLAN Members configured. Alternatively, you can use the
spacebar to toggle through the various configured VLAN workgroups. You can
create up to 64 different VLANs (including VLAN 1).
Default 1
Range 2 to 4094
(continued)
VLAN Configuration
Create VLAN: [ 1 ] VLAN Type: [ Port-Based ]
Delete VLAN: [ ] Protocol Id (PID): [ None ]
VLAN Name: [ VLAN #1 ] User-Defined PID: [ 0x0000 ]
Management VLAN: [ Yes ] VLAN State: [ Active ]
Port Membership
1-6 7-12 13-18 19-24 25
------ ------ ------ ------ ------
Unit #1 UUUUUU UUUUUU UUUUUU UUUUUU
Unit #2 UUUUUU UUUUUU UUUUUU UUUUUU U
Unit #3 UUUUUU UUUUUU UUUUUU UUUUUU
Unit #4 UUUUUU UUUUUU UUUUUU UUUUUU
Enter VLAN Number: 1
KEY: T = Tagged Port Member, U = Untagged Port Member, - = Not a Member of VLAN
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
