Using the Console Interface
309978-D Rev 01 3-61
Table 3-20. Port Configuration Screen Fields
Field Description
Unit Allows you to select the unit number (when stacking is configured) to view or
configure. To view or configure another unit, type its unit number and press [Enter], or
press the spacebar to toggle the unit numbers.
Port Indicates the switch port numbers that correspond to the field values in that row of
the screen (for example, the field values in row 2 apply to switch port 2). The values
that you set in the Switch row will affect all switch ports and, when the switch is part
of a stack, the values that you set in the Stack row will affect all ports in the entire
stack (except the gigabit MDA ports or fiber optic ports, when installed).
Trunk The read-only data displayed in this column indicates the trunks that correspond to
the switch ports specified in the Trunk Members fields of the Trunk Configuration
screen (see “
MultiLink Trunk Configuration” on page 3-64).
Status Allows you to disable any of the switch ports. You can also use this field to control
access to any switch port.
Default Enabled
Range Enabled, Disabled
Link A read-only field that indicates the current link state of the corresponding port, as
follows:
• Up: The port is connected and operational.
• Down: The port is not connected or is not operational.
LnkTrap Allows you to control whether link up/link down traps are sent to the configured trap
sink from the switch.
Default On
Range On, Off
Autonegotiation When enabled, sets the corresponding port speed to match the best service provided
by the connected station, up to 100
Mb/s in full-duplex mode. This field is disabled for
all fiber optic ports.
Default Enabled
Range Enabled, Disabled
Speed/Duplex
1
1
Fiber optic ports can only be set to 100Mbs/Half or 100Mbs/Full.
Allows you to manually configure any port to support an Ethernet speed of 10 Mb/s or
100
Mb/s, in half- or full-duplex mode. This field is set (by default) to 1000 Mb/s,
full-duplex for gigabit ports only.
Default 100Mbs/Half (when Autonegotiation is Disabled)
Range 10Mbs/Half, 10Mbs/Full, 100Mbs/Half, 100Mbs/Full
