Quick Steps to Features
309978-D Rev 01 E-15
Configuring the BayStack 450-2M3/2S3 MDAs
To configure or modify the BayStack 450-2M3/2S3 MDA, follow the flowcharts
in Figures
E-14 to E-16.
Choose ATM MDA Configuration (or press a) from the ATM Configuration Menu
to open the ATM MDA Configuration screen.
Figure E-14. Configuring the BayStack 450-2M3/2S3 MDA (1 of 3)
Yes
No
BS45093A
Assigning LEC
to an existing
VLAN?
Off-page reference
On-page reference
Key
You cannot enable
an LEC without assigning
it to a VLAN.
A
Go to the VLAN Configuration
Menu to assign the LEC:
3. Press v to open the
VLAN Configuration Menu.
2. Press r to return to the
Switch Configuration Menu.
4. Press v to open the VLAN
Configuration screen.
2
1
1. Press [Ctrl]-R to return to the
ATM Configuration Menu.
VLAN Configuration screen
Select the appropriate
ATM MDA to configure.
Press [Ctrl]-R to return to the
ATM Configuration Menu.
Select the appropriate LEC to
configure, then press [Return].
Choose LEC Configuration
(or press l) to open the
LEC Configuration screen.
Configure the appropriate ATM MDA
fields as described in this guide
(see Chapter 3, "ATM MDA Configuration").
Determine the VPort number
that is associated with
the chosen LEC.
A
ATM MDA Configuration screen
LEC Configuration screen
4
To Next Page
