Using the BayStack 450 10/100/1000 Series Switch
2-22 309978-D Rev 01
4. Select IP Configuration/Setup (or press i) from the Main Menu.
This selection displays the IP Configuration/Setup screen (Figure 2-17).
Figure 2-17. IP Configuration/Setup Screen (Stack Configuration)
5. Enter the Stack IP address in the In-Band Stack IP Address field, and
then press [Enter].
The In-Band Switch IP Address field (directly below the In-Band Stack IP
Address field) is not required for the stack operation. The In-Band Switch IP
Address field allows this switch to operate as a standalone switch. You cannot
configure both IP address fields to use the same IP address.
Note: The default management VLAN (IP interface) for the BayStack 450
switch is VLAN 1. However, you can specify which VLAN you want to be the
management VLAN (see
“VLAN Configuration” on page 3-46).
IP Configuration/Setup
BootP Request Mode: [ BootP Disabled ]
Configurable In Use Last BootP
------------------- --------------- ---------------
In-Band Stack IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Switch IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Subnet Mask: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Default Gateway: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
IP Address to Ping: [ 0.0.0.0 ]
Start Ping: [ No ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
