Using the BayStack 450 10/100/1000 Series Switch

3-84 309978-D Rev 01

Figure 3-34. Multicast Group Membership Screen

Table 3-30 describes the Multicast Group Membership screen options.

Table 3-30. Multicast Group Membership Screen Options

Option Description

VLAN Allows you to view IP multicast group addresses on specified VLANs. You can

use the spacebar to view group addresses for any existing IGMP

configurations (the maximum number of VLANs that can be displayed is 64).

Multicast Group Address Displays all the IP multicast group addresses that are currently active on the

associated port.

Port Displays the port numbers that are associated with the IP multicast group

addresses displayed in the Multicast Group Address field.

Multicast Group Membership

VLAN: [ 1 ]

Multicast Group Address Port

------------------------- ----------------

227.37.32.6 Unit: 1 Port: 1

227.37.32.5 Unit: 1 Port: 1

227.37.32.4 Unit: 1 Port: 1

227.37.32.3 Unit: 1 Port: 1

227.37.32.2 Unit: 1 Port: 1

227.37.32.1 Unit: 1 Port: 1

Press Ctrl-P to see previous display. Press Ctrl-N to see more addresses.

Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
