Page #182 background imageLoading...
Page #182 background image
Using the BayStack 450 10/100/1000 Series Switch
3-22 309978-D Rev 01
MAC Address Table
The MAC Address Table screen (Figure 3-7) allows you to view learned MAC
addresses or to search for a specific MAC address.
The MAC Address Table screen also operates in conjunction with the Port
Mirroring Configuration screen. When you configure a switch for MAC
address-based port mirroring, you can use the MAC Address Table screen to find
an address, and enter the address directly from this screen. You can enter
addresses from either screen, but you must return to the Port Mirroring
Configuration screen to activate the feature (see
Port Mirroring Configuration
on page 3-71).
Choose MAC Address Table (or press m) from the Switch Configuration Menu to
open the MAC Address Table screen.
Figure 3-7. MAC Address Table Screen
Note: This screen does not refresh dynamically to show new entries. To
refresh the screen, press [Ctrl]-R to return to the previous menu.
MAC Address Table
Aging Time: [ 300 seconds ]
Find an Address: [ 00-00-00-00-00-00 ]
Port Mirroring Address A: [ 00-44-55-44-55-22 ]
Port Mirroring Address B: [ 00-33-44-33-22-44 ]
00-60-FX-00-02-30
00-00-AX-85-2X-26 Port: 1
00-60-XX-12-02-15 Port: 1
00-08-FX-1D-4X-38 Trunk:3
End of Address Table. Press Ctrl-P to see previous display.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
