Using the Console Interface
309978-D Rev 01 3-21
Rate Limiting Configuration... Displays the Rate Limiting Configuration screen (see “Rate Limiting
Configuration” on page 3-75). This screen allows you to limit the
forwarding rate of broadcast and IP multicast packets.
IGMP Configuration... Displays the IGMP Configuration Menu (see “IGMP Configuration
Menu” on page 3-78). This menu allows you to optimize IP multicast
traffic by setting up IGMP port memberships that filter IP multicast on
a per port basis (see
“IGMP Snooping” on page 1-69 for more
information about this feature).
Display Port Statistics Displays the Port Statistics screen (see “Port Statistics” on
page 3-85). This screen allows you to view detailed information about
any switch port.
Clear All Port Statistics Allows you to clear all port statistics. This option is followed by screen
prompts that precede a choice of actions:
• If the switch is operating standalone, choose one of the following:
• Yes, to clear all port statistics for all switch ports
• No, to abort the option
• If the switch is participating in a stack configuration, choose one of
the following:
• Clear all port statistics for a specific unit in the stack
• Clear all port statistics for the entire stack
• No, to abort the option
ATM Configuration... Displays the ATM Configuration Menu (see “ATM Configuration Menu”
on page 3-89). This menu allows you to select the appropriate screens
to configure or upgrade your ATM MDA.
Return to Main Menu Exits the Switch Configuration Menu and displays the main menu.
Table 3-5. Switch Configuration Menu Options (continued)
Option Description
