Using the Console Interface
309978-D Rev 01 3-73
Table 3-25 describes the Port Mirroring Configuration screen fields.
Table 3-25. Port Mirroring Configuration Screen Fields
Field Description
Monitoring Mode Allows you to select any one of six port-based monitoring modes or any one of five
address-based monitoring modes (see Ta bl e 3-26). Selecting any one of the six
port-based modes activates the port X and port Y screen fields, where you can
choose up to two ports to monitor. Selecting any one of the five address-based
modes activates the Address A and Address B screen fields, where you can specify
MAC addresses to monitor.
Default Disabled
Range See Tabl e 3-26
Monitor Unit/Port Indicates the port number (of the specified unit) that is designated as the monitor
port.
Default Zero-length string
Range 1 to 8 / 1 to 28 (depending on model type)
Unit/Port X Indicates one of the ports (of the specified unit) that will be monitored by the
designated port monitor when one of the port-based monitoring modes is selected.
This port will be monitored according to the value of Port X in the Monitoring Mode
field (see
Tabl e 3-26).
Default Zero-length string
Range 1 to 8 / 1 to 28 (depending on model type)
Unit/Port Y Indicates one of the ports (of the specified unit) that will be monitored by the
designated port monitor when one of the port-based monitoring modes is selected.
When installed as a standalone switch, the screen does not display the (Unit/) field
designation. This port will be monitored according to the value of Port Y in the
Monitoring Mode field (see
Ta bl e 3-26).
Default Zero-length string
Range 1 to 8 / 1 to 28 (depending on model type)
Address A Indicates the MAC addresses that will be monitored by the designated port monitor
when one of the address-based monitoring modes is selected. This port will be
monitored according to the value of Address A in the selected Monitoring Mode field
(see
Tabl e 3-26). Users can enter the MAC address from this screen or from the MAC
Address Table screen. The entry is displayed and can be modified by either screen
(see “
MAC Address Table” on page 3-22).
Default 00-00-00-00-00-00 (no MAC address assigned)
Range 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
(continued)
