Nortel BayStack 450-24T User Manual

Using the Console Interface
309978-D Rev 01 3-89
ATM Configuration Menu
The ATM Configuration Menu (Figure 3-36) allows you to select the appropriate
screen to configure or upgrade your BayStack 450-2M3/2S3 MDA.
Choose ATM Configuration (or press a) from the Switch Configuration Menu to
open the ATM Configuration Menu.
Figure 3-36. ATM Configuration Menu
Note: The BayStack 450-2M3/2S3 MDA does not support the Business Policy
Switch. BayStack 450 switches that are configured with BayStack 450-2M3/
2S3 MDAs will not operate in a mixed-stack configuration that includes one or
more Business Policy Switches.
ATM Configuration Menu
LEC Configuration...
ATM MDA Configuration
MDA Software Download...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.

Nortel BayStack 450-24T Specifications

General

Switching Capacity	8.8 Gbps
Forwarding Rate	35.7 Mpps
Layer	2
Weight	4.5 kg
Flash Memory	8 MB
Jumbo Frame Support	Yes
Manageable	Yes
Power Supply	Internal
Operating Humidity	10% to 90% non-condensing
Features	VLAN, QoS
MAC Address Table	8K
Operating Temperature	0°C to 40°C
Ports	24 x 10/100Base-TX
Uplink Ports	2 x 1000Base-X (SFP)
Dimensions	44.0 x 29.5 x 4.4 cm
MAC Address Table Size	8K
Dimensions (W x D x H)	44.0 x 29.5 x 4.4 cm
