Installing the BayStack 450 Switch
309978-D Rev 01 2-19
Figure 2-14. IP Configuration/Setup Screen (Standalone Switch)
4. Enter the IP address of the switch in the In-Band IP Address field, and
then press [Enter].
5. Enter the IP subnet mask address in the In-Band Subnet Mask field, and
then press [Enter].
6. Enter the default gateway address in the Default Gateway field, and then
press [Enter].
See Chapter 3, “Using the Console Interface,” for detailed descriptions of the
menus and screens you can use to customize your configuration.
Note: When you enter the IP address in the In-Band Stack/Switch IP
Address field, and the In-Band Subnet Mask field is not present, the
software provides an in-use default value for the In-Band Subnet Mask
field, based on the class of the entered IP address.
IP Configuration/Setup
BootP Request Mode: [ BootP Disabled ]
Configurable In Use Last BootP
------------------- --------------- ---------------
In-Band Stack IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Switch IP Address: [ 0.0.0.0 ] 0.0.0.0
In-Band Subnet Mask: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Default Gateway: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
IP Address to Ping: [ 0.0.0.0 ]
Start Ping: [ No ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
