Using the BayStack 450 10/100/1000 Series Switch
1-102 309978-D Rev 01
In this example, port 23 becomes the designated Monitor Port for switch S1 when
you press [Enter] in response to the [Yes] screen prompt.
The Monitoring Mode field [ Address A - > Address B ] indicates that all
traffic transmitted by address A to address B will be monitored by the StackProbe
attached to Monitor Port 23.
Figure 1-62. Port Mirroring Address-Based Screen Example
Note: The screen data displayed at the bottom of the screen changes to show
the new currently active port mirroring configuration after you press [Enter].
Note: When you enter MAC addresses in this screen, they are also displayed
in the MAC Address Table screen (see “
MAC Address Table” on page 3-22).
Port Mirroring Configuration
Monitoring Mode: [ Address A -> Address B ]
Monitor Unit/Port: [ /23 ]
Unit/Port X: [ / ]
Unit/Port Y: [ / ]
Address A: [ 00-44-55-44-55-22 ]
Address B: [ 00-33-44-33-22-44 ]
Is your port mirroring configuration complete? [ Yes ]
Currently Active Port Mirroring Configuration
---------------------------------------------
Monitoring Mode: -> Port X or Port Y -> Monitor Port: 23
Port X: 25 Port Y: 24
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
