Using the Console Interface
309978-D Rev 01 3-71
Port Mirroring Configuration
The Port Mirroring Configuration screen allows you to configure a specific switch
port to monitor up to two specified ports or two MAC addresses. You can specify
port-based monitoring or address-based monitoring. In a stack configuration, you
can monitor ports that reside on different units within the stack.
For more information about the port mirroring feature, see “Port Mirroring
(Conversation Steering)” on page 1-97.
Figure 3-29 shows an example of a Port Mirroring Configuration screen, in a stack
configuration, where port 12 (in stack unit 3) is designated as the monitoring port
for ports 5 and 6 of stack unit 4. When installed as a standalone switch, the screen
does not display the (Unit/) field designation.
Choose Port Mirroring Configuration (or press i) from the Switch Configuration
Menu to open the Port Mirroring Configuration screen.
Last 5 Minutes This read-only field indicates the percentage of packets (of the type specified in the
Traffic Type field) the port used in the last 5 minutes. This field provides a running
average of network activity and is updated every 15 seconds.
Last 30 Minutes This read-only field indicates the percentage of packets (of the type specified in the
Traffic Type field) the port used in the last 30 minutes. This field provides a running
average of network activity and is updated every 15 seconds.
Last Hour This read-only field indicates the percentage of packets (of the type specified in the
Traffic Type field) the port used in the last 60 minutes. This field provides a running
average of network activity and is updated every 15 seconds.
Note: Before configuring port mirroring, see “Port Mirroring Configuration
Rules” on page 1-103.
Table 3-24. MultiLink Trunk Utilization Screen Fields (continued)
Field Description
