Using the Console Interface
309978-D Rev 01 3-39
Table 3-11. MAC Address Security Table Screen Fields
Field Description
Find an Address Allows you to search for a specific MAC address that is used in any of the
MAC Address Security Table screens.
MAC Address Allows you to specify up to 448 MAC addresses that are authorized to access
the switch. You can specify the ports that each MAC address is allowed to
access using the Allowed Source field (see next field description). The
specified MAC address does not take effect until the Allowed Source field is
set to some value (a single unit/port number or a port list value that you
previously configured in the MAC Address Security Port Lists screen). You can
clear an existing MAC address field by entering zero (0) in the field and
pressing [Enter].
Default - - - - - (no address assigned)
Range A range of 6 hexadecimal octets, separated by dashes (IP
multicast
1
and broadcast addresses are not allowed).
1
IP multicast address -- Note that the first octet of any IP multicast address will always be an odd number.
Allowed Source Allows you to specify the ports that each MAC address is allowed to access.
The options for the Allowed Source field include a single unit/port number or a
port list value that you have previously configured in the MAC Address
Security Port Lists screen.
Default - (Blank field)
Range A single unit/port or port list value (for example, 1/3,1/6,S5).
