Figure 3-26. MultiLink Trunk Configuration Screen
Table 3-23 describes the MultiLink Trunk Configuration screen fields.
Table 3-23. MultiLink Trunk Configuration Screen Fields
Field Description
Trunk Column header for the read-only fields in this screen. The read-only data displayed in the
Trunk column indicates the trunk (1 to 6) that corresponds to the switch ports specified in
the user-configurable Trunk Members fields.
Trunk Members
(Unit/Port)
Contains fields in each row that can be configured to create the corresponding trunk.
The Unit value in the (Unit/Port) field is configurable only when the switch (unit) is part of
a stack configuration. It indicates that the trunk members in this row are associated with
the specified unit number configured in the Unit field. Each switch port can only be a
member of a single trunk. The appropriate trunk number for each trunk member
configured within this field is shown adjacent to the corresponding switch port in the Port
Configuration screen and the Spanning Tree Configuration screen.
Default blank field
Range 1 to 8 or 1 to 28 (depending on model type)
(continued)
MultiLink Trunk Configuration
Trunk Trunk Members (Unit/Port) STP Learning Trunk Mode Trunk Status
----- ------------------------------- ------------ --------------- ------------
1 [ 3/6 ][ 3/7 ][ 3/9 ][ 3/17 ] [ Normal ] Basic [ Enabled ]
2 [ 4/25 ][ 4/26 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
3 [ 6/13 ][ 6/14 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
4 [ 5/19 ][ 5/20 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
5 [ 8/22 ][ 8/23 ][ / ][ / ] [ Normal ] Basic [ Enabled ]
6 [ 3/2 ][ 1/2 ][ 7/2 ][ 5/6 ] [ Normal ] Basic [ Disabled ]
Trunk Trunk Name
----- ------------------
1 [ U3:T1 to FS2]
2 [ U4:T2 to S2]
3 [ U6:T3 to S2]
4 [ U5:T4 to S3]
5 [ U8:T5 to S4]
6 [ Distributed Trunk]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
