Using the Console Interface
309978-D Rev 01 3-93
LEC Status Allows you to enable or disable the selected LEC.
Default Disable
Range Disable, Enable
LEC State This read-only field displays the current status of the selected LEC.
Default Disabled
Range Disabled, Idle, Operational, Unknown
ELAN Name Allows you to enter a name for the ELAN that is associated with the selected LEC.
You should also verify that the ELAN you are connecting to exists on the target ATM
switch.
Default default
Range Any ASCII string of up to 20 printable characters
VLAN This read-only field displays the current VLAN that is associated with the selected
LEC. The default configuration for the LEC is 0 (no VLAN assigned).
You can assign a LEC to any currently active port-based VLAN. Use the VLAN
Configuration screen to assign the appropriate VPort number for the LEC to a VLAN.
See
Appendix D, “ATM Overview,” for more information about assigning LECs to a
VLAN.
Default 0
Range 1 to 4094
LEC VPort This read-only field displays the LEC VPort (virtual port) number that is associated
with the selected LEC. This VPort number is also shown on other CI screens (such
as the VLAN Configuration screen or the Spanning Tree Configuration screen, as
appropriate).
Default 13 / 25
The four LECs are assigned VPort numbers that directly relate to
the switch version (12 port or 24 port) where they are installed. For
example, when installed in a 24-port switch, LECs 1, 2, 3, and 4
are assigned as VPorts 25, 26, 27, and 28 respectively.
Range (12-port models) = 13,14,15,16 / (24-port models) = 25,26,27,28
Desired Physical
Port
Allows you to configure the physical port (A1 or A2) for the selected LEC.
Default A1
Range A1, A2
(continued)
Table 3-33. LEC Configuration Screen Fields (continued)
Field Description
