BayStack 450 10/100/1000 Series Switches
309978-D Rev 01 1-99
In the configuration example shown in Figure 1-59, the designated monitor port
(port 23) can be set to monitor traffic in any of the following modes:
Monitor all traffic port X receives.
Monitor all traffic port X transmits.
Monitor all traffic port X receives and transmits.
Monitor all traffic port X receives or port Y transmits.
Monitor all traffic port X receives (destined to port Y) and then port Y
transmits.
Monitor all traffic port X receives/transmits and port Y
receives/transmits (conversations between port X and port Y).
As shown in the Port Mirroring Configuration screen example (Figure 1-60), port
23 is designated as the Monitor Port for ports 24 and 25 in switch S1.
The Monitoring Mode field [ - > Port X or Port Y - > ] indicates that all traffic
received by port X or all traffic transmitted by port Y is currently being monitored
by the StackProbe attached to Monitor Port 23.
The screen data displayed at the bottom of the screen shows the currently active
port mirroring configuration.
Note: The Unit value (in the Unit/Port field) cannot be configured when the
switch is operating standalone. For detailed information about the MultiLink
Trunk Configuration screen fields, see
“MultiLink Trunk Configuration” on
page 3-64.
