Using the BayStack 450 10/100/1000 Series Switch
C-16 309978-D Rev 01
The 450-1GBIC MDA (see Figure C-6) provides a single host port for supported
Gigabit Interface Converters (GBICs).
The GBICs are hot-swappable input/output enhancement components that are
designed for use with your BayStack 450 switch to allow Gigabit Ethernet ports to
link with fiber optic networks.
Figure C-6. 450-1GBIC MDA Front Panel
Table C-6 describes the 450-1GBIC MDA front-panel components.
GBIC
Phy
Link
Activity
450-1GBIC MDA
BS450102A
3
4
450-1GBIC MDA
21
GBIC model with
extractor tabs
GBIC model with
extractor handle
SC connector
