Remote Commands
R&S
®
FSW
920User Manual 1173.9411.02 ─ 43
LIST
Turns on spurious emission measurements.
*RST: AUTO
Example:
SWE:MODE ESP
14.5.7.3 Configuring a Multi-SEM Measurement
In the Spectrum application only, spectrum emissions can be measured for multiple
sub blocks of channels (see Chapter 7.6.4.5, "SEM with Multiple Sub Blocks ("Multi-
SEM")", on page 246). Up to 8 sub blocks (with 7 gaps) can be defined. For each sub
block, the familiar configuration settings concerning ranges, limit lines etc. can be
defined in individual tabs (select the sub block using the <sb> suffix in the correspond-
ing commands). In addition, settings on the sub blocks themselves must be configured.
Useful commands for multi-SEM measurements described elsewhere:
●
[SENSe:]ESPectrum<sb>:RANGe<ri>:MLCalc on page 933
Remote commands exclusive to multi-SEM measurements
[SENSe:]ESPectrum<sb>:SCENter..................................................................................920
[SENSe:]ESPectrum<sb>:SCOunt...................................................................................920
[SENSe:]ESPectrum<sb>:SCENter <Frequency>
This command defines the center frequency of the selected sub block in a Multi-SEM
measurement.
Suffix:
<sb>
.
1 to 8
Sub block in a Multi-SEM measurement
Parameters:
<Frequency> Frequency within the currently defined global span (see
[SENSe:]FREQuency:SPAN on page 1027 and [SENSe:
]FREQuency:CENTer on page 1025).
Range: 1 to 3
*RST: 1
Default unit: Hz
Example:
ESP1:SCEN 1GHZ
Manual operation: See "Sub Block / Center Freq" on page 257
[SENSe:]ESPectrum<sb>:SCOunt <Subblocks>
This command defines the number of sub blocks in the SEM measurement.
Suffix:
<sb>
.
irrelevant
Configuring and Performing Measurements
