Remote Commands

R&S

FSW

981User Manual 1173.9411.02 ─ 43

INITiate<n>[:IMMediate] on page 836

See Chapter 14.5.1, "Performing Measurements", on page 834

14.5.10.3 Retrieving Measurement Results

The following commands query the results for time domain measurements.

Measuring the Mean Power

CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:AVERage:RESult?.......................981

CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:PHOLd:RESult?.......................... 981

CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:RESult?......................................982

CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:AVERage:RESult?

This command queries the average mean time domain power. The query is only possi-

ble if averaging has been activated previously using CALCulate<n>:MARKer<m>:

FUNCtion:SUMMary:AVERage on page 978.

To get a valid result, you have to perform a complete measurement with synchroniza-

tion to the end of the measurement before reading out the result. This is only possible

for single sweep mode.

See also INITiate<n>:CONTinuous on page 835.

Suffix:

<n>

Window

<m> Marker

Return values:

<MeanPower> Mean power of the signal during the measurement time.

Usage: Query only

CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MEAN:PHOLd:RESult?

This command queries the maximum mean time domain power. The query is only pos-

sible if the peak hold function has been activated previously using CALCulate<n>:

MARKer<m>:FUNCtion:SUMMary:PHOLd.
