RL78/G10 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0384EJ0311 Rev. 3.11 442

Dec 22, 2016

Figure 13-22. Flow When Setting WUP0 = 0 upon Address Match (Including Extension Code Reception)

Waits for five cycles of f

CLK

Executes processing corresponding to the operation to be executed

after checking the operation state of serial interface IICA.

STOP mode state

Yes

WUP0 = 0

Wait

Reading IICS0

INTIICA0 = 1?

Use the following flows to perform the processing to release the STOP mode other than by an interrupt request

(INTIICA0) generated from serial interface IICA.

• Master device operation: Flow shown in Figure 13-23

• Slave device operation:

Cases where the trigger for recovery from the STOP mode is the INTIICA0 interrupt:

Same as the flow in Figure 13-22

Cases where the trigger for recovery from the STOP mode is other than the INTIICA0 interrupt:

Continues the operation with WUP0 = 1 until the INTIICA0 interrupt is generated.
