RL78/G10 CHAPTER 2 PIN FUNCTIONS

R01UH0384EJ0311 Rev. 3.11 12

Dec 22, 2016

2.2 Functions other than port pins

2.2.1 Functions for each product

Function

Name

16-pin

products

10-pin

products

Function

Name

16-pin

products

10-pin

products

ANI0 √ √ RxD0 √ √

ANI1 √ √ TxD0 √ √

ANI2 √ √ SCL00 √ √

ANI3 √ √ SDA00 √ √

ANI4 √ — SCK00 √ √

ANI5 √ — SCK01 √ —

ANI6 √ — SI00 √ √

IVCMP0 √ — SI01 √ —

IVREF0 √ — SO00 √ √

VCOUT0 √ — SO01 √ —

INTP0 √ √ SCLA0 √ —

INTP1 √ √ SDAA0 √ —

INTP2 √ — TI00 √ √

INTP3 √ — TO00 √ √

KR0 √ √ TI01 √ √

KR1 √ √ TO01 √ √

KR2 √ √ TI02 √ —

KR3 √ √ TO02 √ —

KR4 √ √ TI03 √ —

KR5 √ √ TO03 √ —

PCLBUZ0 √ √

TOOL0 √ √

RESET √ √

X1 √ —

X2 √ —

EXCLK √ —

VDD √ √

VSS √ √
