RL78/G10 CHAPTER 6 TIMER ARRAY UNIT
R01UH0384EJ0311 Rev. 3.11 117
Dec 22, 2016
6.3 Registers Controlling Timer Array Unit
Timer array unit is controlled by the following registers.
• Peripheral enable register 0 (PER0)
• Timer clock select register 0 (TPS0)
• Timer channel enable status register 0 (TE0, TEH0)
• Timer channel start register 0 (TS0, TSH0)
• Timer channel stop register 0 (TT0, TTH0)
• Timer output enable register 0 (TOE0)
• Timer output register 0 (TO0)
• Timer output level register 0 (TOL0)
• Timer output mode register 0 (TOM0)
• Timer mode register 0n (TMR0nH, TMR0nL)
• Timer status register 0n (TSR0n)
• Noise filter enable register 1 (NFEN1)
• Input switch control register (ISC)
• Port mode control register 0 (PMC0)
• Port mode register 0, 4 (PM0, PM4)
• Port register 0, 4 (P0, P4)
Remark n: Channel number
n = 0, 1 (for 10-pin products); n = 0 to 3 (for 16-pin products)
