19.2 Format of User Option Byte
The format of user option byte is shown below.
Figure 19-1. Format of User Option Byte (000C0H)
Address: 000C0H
7 6 5 4 3 2 1 0
1 1 1 WDTON WDCS2 WDCS1 WDCS0 WDSTBYON
WDTON Operation control of watchdog timer counter
0 Counter operation disabled (counting stopped after reset)
1 Counter operation enabled (counting started after reset)
WDCS2 WDCS1 WDCS0
Overflow Time
(when f
IL = 17.25 kHz (MAX.))
Interval Interrupt Time
(when fIL = 17.25 kHz (MAX.))
0 0 0
(2
6
-1)/fIL (3.65 ms)
2
6
/fIL × 0.75 (2.78 ms)
0 0 1
(2
7
-1)/fIL (7.36 ms)
2
7
/fIL × 0.75 (5.56 ms)
0 1 0
(2
8
-1)/fIL (14.7 ms)
2
8
/fIL × 0.75 (11.1 ms)
0 1 1
(2
9
-1)/fIL (29.6 ms)
2
9
/fIL × 0.75 (22.2 ms)
1 0 0
(2
11
-1)/fIL (118 ms)
2
11
/fIL × 0.75 (89.0 ms)
1 0 1
(2
13
-1)/fIL (474 ms)
2
13
/fIL × 0.75 (356 ms)
1 1 0
(2
14
-1)/fIL (949 ms)
2
14
/fIL × 0.75 (712 ms)
1 1 1
(2
16
-1)/fIL (3799 ms)
2
16
/fIL × 0.75 (2849 ms)
WDSTBYON Operation control of watchdog timer counter (HALT/STOP mode)
0 Counter operation stopped in HALT/STOP mode
1 Counter operation enabled in HALT/STOP mode
Cautions 1. Be sure to write 1 to bits 7 to 5.
2. Setting WDTON = 0 and WDSTBYON = 1 is prohibited.
3. The watchdog timer always generates an interval interrupt when the specified time is
reached unless this is specifically disabled. If the interval interrupt from the watchdog
timer is not to be used, be sure to disable the interrupt by setting the WDTIMK bit to 1.
Remark f
IL: Low-speed on-chip oscillator clock frequency
