RL78/G10 CHAPTER 19 OPTION BYTE

R01UH0384EJ0311 Rev. 3.11 548

Dec 22, 2016

19.4 Setting of Option Byte

The user option byte and on-chip debug option byte can be set using the link option in addition to describing to the

source.

When doing so, the contents set by using the link option take precedence, even if descriptions exist in the source, as

mentioned below.

A software description example of the option byte setting is shown below.

OPT CSEG OPT_BYTE

DB F7H ; Enables watchdog timer operation,

; Overflow time of watchdog timer is 2

/fIL,

; Stops watchdog timer operation during HALT/STOP mode

DB E7H ; Select 2.7 V for V

SPDR

; Use the port function (P125/KR1)

DB FDH ; Select 1.25 MHz as the frequency of the high-speed on-chip oscillator clock

DB 85H ; Enables on-chip debug operation

Caution To specify the option byte by using assembly language, use OPT_BYTE as the relocation attribute

name of the CSEG pseudo instruction.
