RL78/G10
CHAPTER 2 PIN FUNCTIONS
R01UH0384EJ0311 Rev. 3.1
1
15
Dec 22, 2016
2.4 Block Diagrams of Pins
Figures 2-1 to 2-8 show the block diagrams of
the pins described in
2.1.1 10-pin products
and
2.1.2 16-pin products
.
Figure 2-1. Pin Block Diagram fo
r Pin Type 2-1-2
RD
Internal bus
Pmn
Alternate
function
Remark
For alternate functions, see
2.1 Port Functions
.
31
