RL78/G10 CHAPTER 9 WATCHDOG TIMER
R01UH0384EJ0311 Rev. 3.11 239
Dec 22, 2016
9.4.2 Setting time of watchdog timer
Set the overflow time and interval interrupt time of the watchdog timer by using bits 3 to 1 (WDCS2 to WDCS0) of the
option byte (000C0H).
If an overflow occurs, an internal reset signal is generated. The present count is cleared and the watchdog timer starts
counting again by writing “ACH” to the watchdog timer enable register (WDTE) before the overflow time.
When 75% of the overflow time is reached, an interval interrupt is generated.
The following overflow time and interval interrupt time can be set.
Table 9-3. Setting of Overflow Time and Interval Interrupt Time
WDCS2 WDCS1 WDCS0
Overflow Time
(when f
IL = 17.25 kHz (MAX.))
Interval Interrupt Time
(when fIL = 17.25 kHz (MAX.))
0 0 0 (2
6
-1)/fIL (3.65 ms)
2
6
/fIL × 0.75 (2.78 ms)
0 0 1 (2
7
-1)/fIL (7.36 ms)
2
7
/fIL × 0.75 (5.56 ms)
0 1 0 (2
8
-1)/fIL (14.7 ms)
2
8
/fIL × 0.75 (11.1 ms)
0 1 1 (2
9
-1)/fIL (29.6 ms)
2
9
/fIL × 0.75 (22.2 ms)
1 0 0 (2
11
-1)/fIL (118 ms)
2
11
/fIL × 0.75 (89.0 ms)
1 0 1 (2
13
-1)/fIL (474 ms)
2
13
/fIL × 0.75 (356 ms)
1 1 0 (2
14
-1)/fIL (949 ms)
2
14
/fIL × 0.75 (712 ms)
1 1 1 (2
16
-1)/fIL (3799 ms)
2
16
/fIL × 0.75 (2849 ms)
Cautions 1. When operating with the X1 oscillation clock
Note
after releasing the STOP mode, the CPU
starts operating after the oscillation stabilization time has elapsed.
Therefore, if the period between the STOP mode release and the watchdog timer overflow is
short, an overflow occurs during the oscillation stabilization time, causing a reset.
Consequently, set the overflow time in consideration of the oscillation stabilization time
when operating with the X1 oscillation clock
Note
and when the watchdog timer is to be
cleared after the STOP mode release by an interval interrupt.
2. The watchdog timer continues counting even after INTWDTI is generated (until ACH is
written to the watchdog timer enable register (WDTE)). If ACH is not written to the WDTE
register before the overflow time, an internal reset signal is generated.
3. The watchdog timer always generates an interval interrupt when the specified time is
reached unless this is specifically disabled. If the interval interrupt from the watchdog timer
is not to be used, be sure to disable the interrupt by setting the WDTIMK bit to 1.
Note 16-pin products only.
Remark f
IL: Low-speed on-chip oscillator clock frequency
