RL78/G10 CHAPTER 22 BCD CORRECTION CIRCUIT
R01UH0384EJ0311 Rev. 3.11 561
Dec 22, 2016
CHAPTER 22 BCD CORRECTION CIRCUIT
22.1 BCD Correction Circuit Function
The result of addition/subtraction of the BCD (binary-coded decimal) code and BCD code can be obtained as BCD
code with this circuit.
The decimal correction operation result is obtained by performing addition/subtraction having the A register as the
operand and then adding/ subtracting the BCD correction result register (BCDADJ).
22.2 Registers Used by BCD Correction Circuit
The BCD correction circuit uses the following registers.
• BCD correction result register (BCDADJ)
22.2.1 BCD correction result register (BCDADJ)
The BCDADJ register stores correction values for obtaining the add/subtract result as BCD code through add/subtract
instructions using the A register as the operand.
The value read from the BCDADJ register varies depending on the value of the A register when it is read and those of
the CY and AC flags.
The BCDADJ register is read by an 8-bit memory manipulation instruction.
Reset input sets this register to undefined.
Figure 22-1. Format of BCD Correction Result Register (BCDADJ)
Address: F00FEH After reset: undefined R
Symbol 7 6 5 4 3 2 1 0
BCDADJ
