RL78/G10 CHAPTER 24 ELECTRICAL SPECIFICATIONS

R01UH0384EJ0311 Rev. 3.11 604

Dec 22, 2016

24.8 Flash Memory Programming Characteristics

A = 0 to + 40°C, 4.5 V ≤ VDD ≤ 5.5 V, VSS = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Code flash memory

rewritable times

Notes 1, 2, 3

erwr Retained for 20 years. TA = +85°C 1000 Times

Notes 1. 1 erase + 1 write after the erase is regarded as 1 rewrite. The retaining years are until next rewrite after the

rewrite.

2. When using flash memory programmer.

3. These are the characteristics of the flash memory and the results obtained from reliability testing by

Renesas Electronics Corporation.

24.9 Dedicated Flash Memory Programmer Communication (UART)

(TA = 0 to + 40°C, 4.5 V ≤ VDD ≤ 5.5 V, VSS = 0 V)

Parameter Symbol Conditions MIN. TYP. MAX. Unit

Transfer rate 115,200 bps

Remark The transfer rate during flash memory programming is fixed to 115,200 bps.
