RL78/G10 CHAPTER 13 SERIAL INTERFACE IICA

R01UH0384EJ0311 Rev. 3.11 476

Dec 22, 2016

(ii) Extension code

ST AD6 to AD0 R/W ACK D7 to Dn AD6 to AD0 ACK SPST R/W D7 to D0 ACK

2 1

1: IICS0 = 1000×110B

2: IICS0 = 01100010B

Sets LREL0 = 1 by software

3: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

n = 6 to 0

(e) When loss occurs due to stop condition during data transfer

ST AD6 to AD0 R/W ACK D7 to Dn SP

2 1

1: IICS0 = 10000110B

2: IICS0 = 01000001B

Remark

: Always generated

: Generated only when SPIE0 = 1

×: Don’t care

n = 6 to 0
