5.36
SEL-2414 Transformer Monitor Instruction Manual Date Code 20130214
Metering and Monitoring
Monitoring
=>THE D <Enter>
SEL-2414 Date: 12/21/2012 Time: 00:37:34
DEVICE
Transformer 1
Max Max Max Max Max Max
Date Time AMBT TOILC TOILM LOAD HS FAA RLOL TLOL
12/20/2012 0000 24.5 57.3 59.9 0.91 109.6 0.99 0.014 2.345
12/21/2012 0000 24.5 58.4 60.9 0.95 110.8 1.10 0.015 2.360
Transformer 2
Max Max Max Max Max Max
Date Time AMBT TOILC TOILM LOAD HS FAA RLOL TLOL
12/20/2012 0000 24.5 57.3 59.9 0.91 109.6 0.99 0.014 2.345
12/21/2012 0000 24.5 58.4 60.9 0.95 110.8 1.10 0.015 2.360
Transformer 3
Max Max Max Max Max Max
Date Time AMBT TOILC TOILM LOAD HS FAA RLOL TLOL
12/20/2012 0000 24.5 57.3 59.9 0.91 109.6 0.99 0.014 2.345
12/21/2012 0000 24.5 58.4 60.9 0.95 110.8 1.10 0.015 2.360
=>>
Thermal Monitor Reset Functions (THE R, THE C, and THE P Commands)
The THE R and THE C (Reset/Clear Thermal Archives Functions) commands
clear all the thermal archives (daily profile data, hourly profile data, and thermal
event data) and resets the total accumulated loss-of-life value to its preset value
(if it exists) or zero.
Using the THE P n (Load Preset Value of Total Loss of Life) command, the user
can preset the initial loss-of-life values for each phase of the monitored trans-
former. The command must be followed by a value between zero and 100 per-
cent. This command initializes the total loss-of-life value to the preset value
entered by the user and restarts the thermal element. Thermal archive data are not
cleared.
Table 5.17 Daily Profile Quantities
Quantity Description
Max Ambient Maximum ambient temperature
Max Calc Top Oil Maximum calculated top-oil temperature
Max Msd Top Oil Maximum measured top-oil temperature
Max Hot Spot Maximum winding hot-spot temperature
Max Load Maximum per-unit load
Max FAA Maximum insulation aging acceleration factor (FAA)
RLOL Daily 24-hour accumulated loss of life (value of accumulated 24-hour
loss of life at midnight)
TLOL Total accumulated loss of life (sum of the daily 24-hour accumulated
loss of life values)
