Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
SEL-2414 Transformer Monitor
Command Summary
Instruction Manual
The table below lists the front serial port ASCII commands associated with particular activities. The commands are
shown in uppercase letters, but they can also be entered using lowercase letters.
Serial Port Command Command Description
Access Level 0 Commands
ACC Go to Access Level 1.
BNA Display ASCII names of all the Device Word bits returned in the Fast Meter Data Block.
CAS Return the Compressed ASCII configuration message.
DNA Display ASCII names of Device Word bits reported in Fast Meter.
ID Device identification code.
QUI Go to Access Level 0.
SNS Display SER settings in Compressed ASCII format.
Access Level 1 Commands
2AC Go to Access Level 2.
CEV n Display compressed event report, 15 cycles (n is the event report).
CEV n R Display compressed event report with raw (unfiltered) data, 16 or 65 cycles.
CHI Display compressed history report.
CME A Display fundamental metering data in compressed format.
CME F Display fundamental metering data in compressed format.
CME M Display math variable metering data in compressed format.
CME RE Display remote analog metering data in compressed format.
COM A Return a summary report of the last 255 records in the communications buffer for M
IRRORED BITS
®
communications Channel A.
COM B Return a summary report of the last 255 records in the communications buffer for M
IRRORED BITS
communications Channel B.
COM C Clears all communications records. If both M
IRRORED BITS channels are enabled, omitting
the channel specifier (A or B) clears both channels.
COM C A Clears all communications records for Channel A.
COM C B Clears all communications records for Channel B.
COM L Appends a long report to the summary report of the last 255 records in the M
IRRORED BITS communications
buffer.
COM L A Appends a long report to the summary report of the last 255 records in the communications buffer for
M
IRRORED BITS communications Channel A.
