1.3
Date Code 20130214 Instruction Manual SEL-2414 Transformer Monitor
Introduction and Specifications
Models, Options, and Accessories
Metering
Communications
Protocols
Models, Options, and Accessories
Models
This manual does not provide complete ordering information. For complete
information, see the latest SEL-2414 Model Option Table (MOT) at
www.selinc.com, under SEL Literature, Ordering Information (Model Option
Tables).
The SEL-2414 surface mount option uses the SEL-2414 and the surface mount-
ing bracket for easy access to the rear connections. The SEL-2414 surface mount
option enables mounting in confined locations where only remote control and
rear-panel access is required.
Options
The SEL-2414 contains six slots for cards. Slot A must be used for the power
supply and Slot B must be used for the mainboard. The other four slots (Slot C,
Slot D, Slot E, and Slot Z) may be configured with option cards that, except for
the input/output cards, must be installed in specific slots on the device. The input/
output cards may be installed in any (or all) of Slot C through Slot Z. Table 1.1
shows the possible cards configurations (see Section 2: Installation for more
information).
Standard
Metering
➤ Temperature (Analog Input)
➤ Fundamental
➤ Energy
➤ Maximum and Minimum
➤ Demand
➤ Analog Input
➤ Math Variable
➤ Remote Analog
Analog Signal Profiling
Optional
Thermal (with the external SEL-2600 RTD Module, internal RTD option, or internal RTD/
TC option)
Standard
Modbus
®
RTU Slave or Modbus TCP
a
a
With optional Ethernet port.
Ethernet FTP
a
and Telnet
a
SEL MIRRORED BITS
®
SEL ASCII, Compressed ASCII, Fast Meter, Fast Operate, Fast SER, and Fast Message pro-
tocols
Optional
DNP3 Level 2 Slave (LAN/WAN
a
and Serial)
IEC 61850 Communications
a
